X28C512, X28C513
Plastic Leaded Chip Carrier Packages (PLCC)
0.042 (1.07)
0.048 (1.22)
PIN (1)
IDENTIFIER
CL
0 .042   (1.07 )
0.056 (1.42)
0.050 (1.27) T P
ND
0.004 (0.10)
0 .025   (0.64 )
0.045 (1.14)
C
R
N32.45x55 (JEDEC MS-016AE ISSUE A)
32 LEAD PLASTIC LEADED CHIP CARRIER PACKAGE
INCHES MILLIMETERS
SYMBOL MIN MAX MIN MAX NOTES
A
A1
0.125
0.060
0.140
0.095
3.18
1.53
3.55
2.41
-
-
D2/E2
D
0.485
0.495
12.32
12.57
-
NE
D1
D
E1 E
CL
A1
A
D2/E2
VIEW “A”
0.015 (0.38)
MIN
D1
D2
E
E1
E2
N
ND
NE
0.447
0.188
0.585
0.547
0.238
28
7
9
0.453
0.223
0.595
0.553
0.273
11.36
4.78
14.86
13.90
6.05
28
7
9
11.50
5.66
15.11
14.04
6.93
3
4, 5
-
3
4, 5
6
7
7
-C- PLANE
0.020 (0.51) MAX
3 PLCS
0.050 (1.27)
MIN
0.026 (0.66)
0.032 (0.81)
SEATING
Rev. 0 7/98
NOTES:
1. Controlling dimension: INCH. Converted millimeter dimen-
sions are not necessarily exact.
2. Dimensions and tolerancing per ANSI Y14.5M-1982.
3. Dimensions D1 and E1 do not include mold protrusions. Al-
lowable mold protrusion is 0.010 inch (0.25mm) per side.
M A S -B S D S
0.025 (0.64)
MIN
0.013 (0.33)
0.021 (0.53)
(0.12)
0.005
VIEW “A” TYP.
20
Dimensions D1 and E1 include mold mismatch and are mea-
sured at the extreme material condition at the body parting
line.
4. To be measured at seating plane -C- contact point.
5. Centerline to be determined where center leads exit plastic
body.
6. “N” is the number of terminal positions.
7. ND denotes the number of leads on the two shorts sides of the
package, one of which contains pin #1. NE denotes the num-
ber of leads on the two long sides of the package.
FN8106.2
June 7, 2006
